4 Wireless Camera System

Wireless technology has never been so affordable and easy to use. This 4 camera security system comes pre-programed. That means to set up the system all you'll have to do provide power and the system will do the rest. These cameras support wireless transmission up to 300ft line of sight to bring you a very clear picture of 420 TV lines for facial recognition up to 25ft. This camera is also rated for indoor and outdoor use year round with a night vision range up to 60ft.

The DVR in this system comes equipped with smartphone and computer live viewing. This DVR is also equipped with the latest in video compression technology H.264, which means your recording will be the highest quality and still take up the least space on your hard drive. This DVR also comes with continuous/Schedule/Alarm/Motion Detect, Individual channel schedule recording setup.

•
  •

    Features:

    • H.264 Baseline - 4 recording video quality or user defined
    • Multiplex 4CH H.264 DVR: live, recording, playback, backup, network access and control
    • Privacy Mask, Video Loss, Alarm schedule, PTZ, remote/mouse control
    • Support 1 x SATA HDD up to 2TB, USB Backup with AVI/MPEG4/H264 formats
    • Alarm 4CH In and 1CH Out, Audio 1CH In/1CH Out / TV out and VGA out(up to 1280 x 1024)
    • Rotation Display and lock cameras(only Admin can view locally/remotely)
    • individual channel setup for schedule, resolution(CIF, HD1, D1), video quality, and FPSv
    • Multiple channels linkage recording for Motion and Alarm
    • CMS and Mobile Streaming Players for 3G/3.5G mobile phone/PDA (Symbian/Windows Mobile/iPhone/iPad/Blackberry/Android)

    Specifications:

    Wireless Camera Power	10mW~100mW
    Frequency Range	2402~2478MHZ
    Input Signal Level Range	-85~-10dBm
    Camera Wireless	CMOS Camera(24IR)x4
    Video Compression	MPEG4
    Wamera FPS and Resolution	VGA:640X480-30fps
    RECEIVER Antenna	Omni-Directional(Antenna Gain 3dBi)x2
    Modulation	GMSK
    Data rate	up to 4Mbps,100M transmission distance(open site)
    Noise Figure	3dB
    Video Input/Output Format	NTSC/PAL: BNC 1CH In/1CH Out
    Display Resolution	NTSC 704 x 480, PAL 704 x 576, real time per channel
    Compression Method	Video: H.264 Audio: ADPCM
    Recording / PLAYBACK	NTSC 60/704 x 480, 120/704 x 240, 120/352 x 240
    Frame rate(FPS) & Resolution	PAL 50/704 x 576, 100/704 x 288, 100/352 x 288
    Recording Time	7~23 days with 500GB HDD for Continuous Recording mode@25fps
    Recording Mode	Continuous/Schedule/Alarm/Motion Detect, Individual channel schedule recording setup
    Hard Disk Capacity	1 x SATA HDD up to 2000GB
    Media Backup	1 USB 2.0 ports for Flash Disk, DVD Burner, portable HDD backup.
    Sensors, Alarm	4 Inputs, 1 Output(NC, NO relay)
    Alarm Type	Motion, Sensor, Video loss, Multiple channel Recording for Motion and Alarm
    Audio	1CH Out
    Network	RJ-45 10/100BaseT Ethernet connector(PPPoE, DHCP, DDNS, Static IP),UPnP and FTP
    I/R Remote Controller	Yes
    Power Supply	DC12V/5A for AC Adaptor
    Operating Temperature	0°C ~ +40°C
    Dimension	315(W)x224(D)x52(H)mm
